BC103-2/4D

The BC103 thermostat with high definition LCD has very versatile features cover a broad range of applications

Adopt Double-IsolationTM technology to control Fan coil, DX, Split Unit and Heat Pump safely and efficiently

Super modern appearance design, suitable for once, hotel and residential buildings

Benifits

What Double-IsolationTM technology brings to you?
Safe:
1. Safe installation: reduce 50% installation failure rate
2. Safe to use: new technology to protect your family
3. Extra & consistently equipment protection
Comfort:
Precise temperature control makes comfort environment
Easy to install, easy to use
Energy Saving:
1. Up to 30% energy saving solution.
2. Run HVAC more efficient than other thermostat
Smart:
Smart season auto changeover. Preheat function avoid any cold air blow in winter.

Features

Feature NEW INTELLIGENT THERMOSTAT
Model No BC103-2 BC103-4/4D
Supply Voltage 85~230Vac /24Vac. 50/60Hz
Control Device 2-pipe FCU 2pipe/4-pipe FCU, DX Unit
Switch Rating 5A (7A as optional)
Max.Fan Load 1A/3A inductive, 3A resistive
Fan Control Single or 3-speed and Auto
Valve Control On/Off
Heat/Cool Cool/Heat Cool&Heat&Auto
Remote Sensor Yes
Communication Optional
Hotel Card Yes
Backlight White
Temperature Display Celsius/Fahrenheit
Programmable Optional
Setpoint Range 5~35C
Temperature Display 0.5C
Ambiente Storage:-20C~60C, Operating:  0~50°C, Humidity:5~95%
Product Color White RAL9010
Cycling Fan Yes
Approval EN60730-1, CE Standard
Installation  Flush/Surface Mounting
Housing Material PC+ABS
IP Grade IP 30

Dimension & Model No
