BC207-HA

The BC207 series are the luxury TFT colorful touch screen programmable thermostats, for Boiler/Valve/Underfloor Water System control

Thermostats adopt Double-IsolationTM technology to make your heating system effciency and saftey.

Luxury design and friendly user interface which are suitable for high end offices, 5-star hotels and all luxury commercial and residential buildings

Benefit

What Double-IsolationTM technology brings to you?
Safe:
1. Safe installation: reduce 50% installation failure rate
2. Safe to use: new technology to protect your family and electronic circuit
3. Protect equipment consistently: extra protection technology prevent system burned or failure
Comfort:
Precise temperature control provides you a comfort environment.
Easy:
Easy to install
Easy to read and operate
Energy Saving:
1. Up to 50% energy saving solution.
2. Run your system more efficient than other regular thermostats.

Feature

Feature Luxry Color Touch Screen
Model No BC207-HA
Supply Voltage 85~230Vac,50/60Hz
Control Device Boiler/Valve/Under floor Heating
Switch Rating 16A at 230Vac
Screen Type 3.5inches Colorful Touch Screen
Screen Display 320*480 Pixel/Capacitive touch
Language English / Chinese / Spain / Italian / Russian / Polish / Czech / German / French
Temperature Range 5~35C
Humidity Sensor ±3%
Timer Mode Yes
Remote Sensor Remote sensor
Temperature Format Celsius
Prrogrammable 7days/5+2days/Non-programmable
Output Volt free switch /Switch Live
Sensor Temperature Sensor NTC10K
Temperature Display Accuracy: 0.1°C
Tenperature Control Accuracy: 0.5°C
Ambiente Storage:-20°C~60°C, Operating: 0~50°C, Humidity:5~95%
Product Color White/Black
Approval II as per EN60730-1, CE Standard
Installation Flush/Surface Mounting
Housing Material PC+ABS / poly blend – UV stabilised and fire rated
IP Grade IP 30

Installation and Dimension
